P0713

DTC P0713 TRANSMISSION FLUID TEMPERATURE SENSOR CIRCUIT HIGH INPUT

DTC DETECTING CONDITION:
Input signal circuit to ATF temperature sensor is shorted.

TROUBLE SYMPTOM:
Excessive shift shock

WIRING DIAGRAM:
