Restraint Systems
DTC 62 BELT PRETENSIONER LH FAILUREDTC DETECTING CONDITION:
- Seat belt pretensioner (LH) circuit is shorted to ground.
- Pretensioner (LH) is faulty.
- Pretensioner harness is faulty.
- Airbag control module is faulty.
CAUTION: Before performing diagnosis, refer to "CAUTION" in "General Description". Service and Repair
WIRING DIAGRAM:
