C0054-BLS On Malfunction
DTC C0054 BLS ON MALFUNCTIONDTC DETECTING CONDITION:
Defective stop light switch
TROUBLE SYMPTOM:
^ VDC does not operate.
^ Hill start assist does not operate.
WIRING DIAGRAM:
DTC DETECTING CONDITION:
Defective stop light switch
TROUBLE SYMPTOM:
^ VDC does not operate.
^ Hill start assist does not operate.
WIRING DIAGRAM:
