B1621
DTC B1621 MODE DOOR ACTUATOR POTENTIOMETER CIRCUIT SHORTDTC DETECTING CONDITION:
- Mode door does not move.
- The potentiometer value of the actuator does not change.
TROUBLE SYMPTOM:
Vent does not change.
WIRING DIAGRAM:
DTC DETECTING CONDITION:
- Mode door does not move.
- The potentiometer value of the actuator does not change.
TROUBLE SYMPTOM:
Vent does not change.
WIRING DIAGRAM:
