B1606

DTC B1606 REFRIGERANT FLOW SENSOR CIRCUIT SHORT

DTC DETECTING CONDITION:
Refrigerant pressure sensor circuit is shorted.

TROUBLE SYMPTOM:
Compressor does not operate.

WIRING DIAGRAM:
