Camshaft position sensor LH

WARNING: This page is about a different variant/trim than selected.

Disconnect the ground cable from battery.

Fig 1: Disconnecting Ground Cable From Battery
Courtesy of SUBARU OF AMERICA, INC.
Remove the intake manifold. Refer to , REMOVAL , Intake Manifold.
Remove the camshaft position sensor LH.

Fig 2: Locating LH Camshaft Position Sensor
Courtesy of SUBARU OF AMERICA, INC.
