Pressure Control Solenoid Valve: Removal

WARNING: This page is about a different variant/trim than selected.

Disconnect the ground cable from battery.

Fig 1: Identifying Battery Ground Cable
Courtesy of SUBARU OF AMERICA, INC.
Lift up the vehicle.
Disconnect connector (A) from the pressure control solenoid valve.
Disconnect the PCV drain hose (B), PCV inlet hose (C) and PCV outlet hose (D) from the pressure control solenoid valve.
Remove the nuts securing the bracket to the fuel tank and remove the pressure control solenoid valve together with the bracket.

Fig 2: Identifying PCV Drain Hose, PCV Inlet Hose And PCV Outlet Hose
Courtesy of SUBARU OF AMERICA, INC.
Remove the pressure control solenoid valve from the bracket.

Fig 3: Locating Pressure Control Solenoid Valve
Courtesy of SUBARU OF AMERICA, INC.
