Oil Pressure Switch: Removal

  1. Disconnect the ground cable from battery.
    Fig 1: Identifying Battery Ground Cable
    G06648556Courtesy of SUBARU OF AMERICA, INC.
  2. Remove the generator. Ref. to REMOVAL , Generator.
  3. Disconnect the terminal from oil pressure switch.
    Fig 2: Locating Oil Pressure Switch
    G06648557Courtesy of SUBARU OF AMERICA, INC.
  4. Remove the oil pressure switch.
    Fig 3: Locating Oil Pressure Switch
    G06648558Courtesy of SUBARU OF AMERICA, INC.
