P1707

DTC P1707 AT AWD SOLENOID VALVE CIRCUIT MALFUNCTION

The content of this article/image reflects the changes Identified in
TSB # 18-124-08 dated 01/31/08




DTC DETECTING CONDITION:
Output signal circuit of transfer duty solenoid is open or shorted.

TROUBLE SYMPTOM:
^ Tight corner braking phenomenon occurs.
^ Front wheel slips on the slippery road.

WIRING DIAGRAM:
