P0758
DTC P0758 SHIFT SOLENOID "B" ELECTRICALThe content of this article/image reflects the changes Identified in
TSB # 18-124-08 dated 01/31/08
DTC DETECTING CONDITION:
Output signal circuit of 2-4 brake duty solenoid is open or shorted.
TROUBLE SYMPTOM:
Excessive shift shock
WIRING DIAGRAM:
