BLS CIRCUIT OPEN

DTC C0054 BLS CIRCUIT OPEN

DTC DETECTING CONDITION
Defective stop light switch

TROUBLE SYMPTOM
^ ABS does not operate.
^ VDC does not operate.

WIRING DIAGRAM

WIRING DIAGRAM:




AH: C0054 BLS CIRCUIT OPEN:
