P1817

DTC P1817 SPORT MODE SWITCH CIRCUIT

DTC DETECTING CONDITION
- Input signal circuit of SPORT shift switch is open or shorted.

TROUBLE SYMPTOM
- The manual mode is not engaged.
- The SPORT indicator light does not illuminate.
- No SPORT mode occurs.











WIRING DIAGRAM
