P1708

DTC P1708 THROTTLE POSITION SENSOR CIRCUIT LOW INPUT

DTC DETECTING CONDITION
- The input signal circuit of accelerator pedal position sensor is open or shorted.

TROUBLE SYMPTOM
- Shift point is too high or too low.
- Excessive shift shock
- Tight corner braking phenomenon is occurred.











WIRING DIAGRAM
