P0801

DTC P0801 REVERSE INHIBIT CONTROL CIRCUIT

DTC DETECTING CONDITION
- Shift lock solenoid malfunction, open or short reverse inhibitor control circuit

TROUBLE SYMPTOM
- Gear is shifted from N range to R range during driving at 20 km/h (12 MPH) or more.
- Gear cannot be shifted from N range to R range.











WIRING DIAGRAM
