P0743
DTC P0743 TORQUE CONVERTER CLUTCH CIRCUIT ELECTRICALDTC DETECTING CONDITION
- Output signal circuit of lock-up duty solenoid is open or shorted.
TROUBLE SYMPTOM
- No lock-up occurs. (After engine is warmed-up)
WIRING DIAGRAM
DTC DETECTING CONDITION
- Output signal circuit of lock-up duty solenoid is open or shorted.
TROUBLE SYMPTOM
- No lock-up occurs. (After engine is warmed-up)
WIRING DIAGRAM
