P0725

DTC P0725 ENGINE SPEED INPUT CIRCUIT

DTC DETECTING CONDITION
- Engine speed input signal circuit is open or shorted.

TROUBLE SYMPTOM
- No lock-up occurs. (After engine is warmed-up)
- SPORT indicator light remains on when the vehicle speed is 0.











WIRING DIAGRAM
