P0720
DTC P0720 OUTPUT SPEED SENSOR CIRCUITDTC DETECTING CONDITION
- The vehicle speed signal is abnormal.
- The harness connector between TCM and vehicle speed sensor is shorted or open.
TROUBLE SYMPTOM
- Poor driving performance
WIRING DIAGRAM
DTC DETECTING CONDITION
- The vehicle speed signal is abnormal.
- The harness connector between TCM and vehicle speed sensor is shorted or open.
TROUBLE SYMPTOM
- Poor driving performance
WIRING DIAGRAM
