P0719

DTC P0719 TORQUE CONVERTER/BRAKE SWITCH B CIRCUIT LOW

DTC DETECTING CONDITION
- Brake switch malfunction, open input signal circuit

TROUBLE SYMPTOM
- Gear is not shifted down when driving a down hill.








WIRING DIAGRAM
