Section 9 (Diagnostic Trouble Code (DTC) Detecting Criteria (H4SO))
>>
Diagnostic Trouble Code (DTC) Detecting Criteria
>>
DTC P0420 Catalyst System Efficiency Below Threshold (Bank 1)
>>
Diagnostic Method
Diagnostic Method
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Identifying Diagnostic Method
Courtesy of SUBARU OF AMERICA, INC.
