Section 9 (Diagnostic Trouble Code (DTC) Detecting Criteria (H4SO))
>>
Diagnostic Trouble Code (DTC) Detecting Criteria
>>
DTC P0171 System Too Lean (Bank 1)
>>
Outline Of Diagnosis
>>
Fuel System Diagnosis
Fuel System Diagnosis
WARNING:
This page is about a different variant/trim than selected.
Fig 1: DTC P0171 System Too Lean - Description Diagram (Bank 1)
Courtesy of SUBARU OF AMERICA, INC.
