Solenoid valve, actuator, emission control system parts and ignition system parts

WARNING: This page is about a different variant/trim than selected.

Fig 1: Identifying Electrical Component Location (Solenoid valve, Actuator, Emission Control & Ignition System Parts) (1Of 3)

Courtesy of SUBARU OF AMERICA, INC.

Fig 2: Identifying Electrical Component Location (Solenoid valve, Actuator, Emission Control & Ignition System Parts)(2 Of 3)

Courtesy of SUBARU OF AMERICA, INC.

Fig 3: Identifying Electrical Component Location (Solenoid valve, Actuator, Emission Control & Ignition System Parts)(3 Of 3)

Courtesy of SUBARU OF AMERICA, INC.
