Draining Of Engine Coolant

WARNING: This page is about a different variant/trim than selected.
  1. Lift-up the vehicle.
  2. Remove the under cover.
  3. Remove the drain plug to drain engine coolant into container.
    NOTE:

    Remove the coolant filler tank cap so that engine coolant will drain faster.

    Fig 1: Removing Coolant Filler Tank Cap
    G03829786Courtesy of SUBARU OF AMERICA, INC.
  4. Install the drain plug.
