Yaw Rate Sensor Reference

DTC C0072 YAW RATE SENSOR REFERENCE
DTC DETECTING CONDITION:
Defective yaw rate sensor

TROUBLE SYMPTOM: VDC does not operate.











WIRING DIAGRAM
