Excessive Variation Amount of Yaw Rate Sensor Output

DTC C0072 EXCESSIVE VARIATION AMOUNT OF YAW RATE SENSOR OUTPUT
DTC DETECTING CONDITION:
Defective yaw rate sensor

TROUBLE SYMPTOM: VDC does not operate.











WIRING DIAGRAM
