C0041

DTC C0041 VDC CONTROL MODULE MALFUNCTION
DTC DETECTING CONDITION:
Defective VDCCM&H/U

TROUBLE SYMPTOM:
- ABS does not operate.
- EBD does not operate.
- VDC does not operate.











WIRING DIAGRAM
