Alignment Of Height Between Sunroof Lid And Roof Panel

Loosen sunroof lid nuts and then adjust height by adding (max: four pieces) or extracting (min: zero piece) shims (standard: two pieces) between sunroof lid and roof panel.

Difference in height between sunroof lid and roof panel

2.0+/-1.0 mm (0.079+/-0.0.39 in)

Fig 1: Loosening Sunroof Lid Nuts

Courtesy of SUBARU OF AMERICA, INC.
