Engine Mechanical
>>
Cooling Fan
>>
Electric Cooling Fan
>>
Diagnostic Tests (Low Mode With A/C)
>>
Test 1: Checking Power Supply To Main Fan Relay-1
Test 1: Checking Power Supply To Main Fan Relay-1
To check power supply to main fan relay-1, see
Fig 1
.
Fig 1: Checking Power Supply To Main Fan Relay-1
Courtesy of SUBARU OF AMERICA, INC.
