Transfer Case Disassembly

Remove neutral switch. Remove shifter arm and selector arm. See Fig 1. Remove plug, spring, and reverse check ball. Remove reverse check sleeve, back-up light switch, and oil guide.

Fig 1: Exploded View Of Transfer Case

Courtesy of SUBARU OF AMERICA, INC.
