Suspension - Rear: Description

Rear suspension is a semi-trailing arm, independent type. Crossmember is mounted to body frame with brackets at both ends via bushings. See Figure or Figure .

One end of trailing arm is bolted to crossmember through a bushing, and other end is mounted to body through shock absorber. An outer arm is bolted on one end to crossmember through a bushing, and other end is directly bolted to trailing arm.
