Fuel Gauge
Unplug fuel tank sending unit. Connect a 7-ohm resistor between sending unit wire and ground. Resistor should make gauge read empty, 33-ohm resistor should make gauge read 1/2 full and a 95-ohm resistor should make gauge read full.
Unplug fuel tank sending unit. Connect a 7-ohm resistor between sending unit wire and ground. Resistor should make gauge read empty, 33-ohm resistor should make gauge read 1/2 full and a 95-ohm resistor should make gauge read full.
