Steering Gear: Removal
- Disconnect battery negative terminal. Raise and support front of vehicle. Remove both front wheels. Disconnect ball joints from steering knuckles.
- Disconnect flexible coupling from pinion gear. Remove hot air stove from exhaust manifold and air cleaner. Disconnect exhaust manifold and pull down out of way. Remove rubber boot protector.
Courtesy of SUBARU OF AMERICA, INC.
- Remove bolts attaching steering gear housing to crossmember. Lower gear housing until pinion gear is disconnected from flexible coupling. Rotate gear housing backwards and remove gear housing from left side.
