Remove/Install Steering Column Cover - AR68.30-P-2000SR

MODEL 453

Courtesy of MERCEDES-BENZ USA

	Remove/install
1	Withdraw ignition key
2	Remove screws (4)
3	Unclip upper steering column trim (1) in direction of arrow (A) and remove upward	: When installing, ensure that the lower steering column trim (2) and upper steering column trim (1) arrest. Mounting wedge	Figure
4	Fold lever (3) downward and hold in this position	Steering wheel adjustment automatically moves to uppermost position.
5	Pivot lower steering column trim (2) in direction of arrow (B) and remove
6	Install in the reverse order

Fig 1: Identifying Mounting Wedge (110 589 03 59 00)

Courtesy of MERCEDES-BENZ USA
