Prepare Mounting Bracket For Engine Suspension For Installation - Ar64.10-P-2000-02SR

Model 453.0/3/4

1. Grind mating surfaces on mounting console (1) down to bare metal in the crosshatched areas.

   Sand down spot weld flanges to bare metal on both sides.

2. Remove grinding dust and drill chips.
3. Coat insides of spot weld flanges with zinc dust paint.

   Do not coat bonding surfaces with zinc dust paint (areas G and F).

   Otherwise adhesion problems may occur.

   Fig 1: Locating Areas G & F

   Courtesy of MERCEDES-BENZ USA
