Taxi/rental vehicle, function - GF82.25-P-0019FL
WARNING: This page does not describe the selected car, but rather 33 other vehicles, including the 2016 Mercedes-Benz E63 S AMG, 2016 Mercedes-Benz E400, 2016 Mercedes-Benz E350, 2016 Mercedes-Benz E300, and 2016 Mercedes-Benz E250. However, it is still accessible from the selected car via links, so may be relevant.
MODEL 212 with CODE 965 (Electrical preinstallation, rental vehicles)
Function requirements, general
- Circuit 30 ON
Taxi/rental vehicle function, general
The taxi/rental vehicle base function contains the special-purpose vehicle multifunction control unit to control and monitor various functions, the taxi two-way radio speaker and a specific vehicle wiring harness that enables the following equipment to be integrated:
- Taxi emergency alarm system radio remote triggering transmitter (with code (934) Taxi emergency alarm system)
- Taxi emergency alarm system "Delete" button (with code (934) Taxi emergency alarm system)
- Taxi emergency alarm system "Trigger" button (with code (934) Taxi emergency alarm system)
- Two-way radio (accessory)
- Radio data transceiver (accessories)
- Taximeter (with code (336) Preinstallation for taximeter installation)
- Mirror taximeter (with code (337) Taximeter integrated into rearview mirror)
- Roof sign lamp (with code (342) Roof sign connection for taxi)
- Two-way radio connection switch (with code (938) Preinstallation for hands-free two-way radio)
The individual functions are enabled using the diagnostic tester.
The taxi/rental vehicle function consists of the following subfunctions, which are described in separate documents:
- Emergency alarm, function (with code (934) Taxi emergency alarm system)
- Mirror taximeter/mirror odometer, function (with code (337) Taximeter integrated into rearview mirror)
- Two-way radio hands-free system function (with code (938) Preinstallation for hands-free two-way radio)
- Two-way radio integration, function (with code (941) Preinstallation for radio data transmission)
| Emergency alarm function | MODEL 212 with CODE 934 (Taxi emergency alarm unit) with CODE 965 (Electrical preinstallation, rental vehicles) | GF82.25-P-2011FL | |
| Mirror taximeter/mirror odometer function | MODEL 212 with CODE 337 (Taximeter integr. in the rear-view mirror) with CODE 965 (Electrical preinstallation, rental vehicles) | GF82.25-P-2012FL | |
| Two-way radio handsfree system function | MODEL 212 with CODE 938 (Preinstallation for hands-free two-way radio) with CODE 965 (Electrical preinstallation, rental vehicles) | GF82.25-P-2013FL | |
| Two-way radio integration function | MODEL 212 with CODE 941 (Preinstallation for radio data transmission) with CODE 965 (Electrical preinstallation, rental vehicles) | GF82.25-P-2014FL |
