| A1 |
Instrument cluster |
35L |
| A45 |
Fanfare horns and airbag clock spring contact |
18H |
| A45x1 |
Clock spring contact and airbag connector |
|
| A53 |
Driver head/thorax sensor |
14L |
| A54 |
Front passenger head/thorax sensor |
10L |
| B48/1 |
Driver-side frontal acceleration sensor |
12L |
| B48/2 |
Passenger-side frontal acceleration sensor |
8L |
| B48/3 |
Belt tension sensor |
41L |
| B48/3x1 |
Belt tension sensor connector |
|
| B48/4 |
Seat occupied recognition pressure sensor |
43L |
| B48/4x1 |
Seat occupied recognition pressure sensor connector |
|
| E16 |
Automatic child seat recognition airbag OFF indicator lamp |
6L |
| N10/10 |
SAM control unit |
3L |
| N10/10f18 |
Fuse 18 |
4L |
| N110 |
Weight Sensing System (WSS) control unit |
42A |
| N110 |
Weight Sensing System (WSS) control unit |
38A |
| N2/7 |
Restraint systems control module |
34A |
| N2/7 |
Restraint systems control module |
28A |
| N2/7 |
Restraint systems control module |
20A |
| N2/7 |
Restraint systems control module |
12A |
| N2/7 |
Restraint systems control module |
4A |
| R12/1 |
Left emergency tensioning retractor squib |
21L |
| R12/13 |
Driver airbag ignition squib 1 |
18L |
| R12/14 |
Driver airbag ignition squib 2 |
19L |
| R12/1x1 |
Left emergency tensioning retractor squib connector |
|
| R12/2 |
Right emergency tensioning retractor squib |
23L |
| R12/20 |
Driver head/thoraxbag squib |
26L |
| R12/21 |
Front passenger head/thoraxbag squib |
25L |
| R12/2x1 |
Right emergency tensioning retractor squib connector |
|
| R12/4 |
Front passenger airbag ignition squib 1 |
15L |
| R12/5 |
Front passenger airbag ignition squib 2 |
17L |
| S68/3 |
Driver-side seat belt buckle restraint systems switch |
29L |
| S68/4 |
Passenger-side seat belt buckle restraint systems switch |
31L |
| W26 |
Ground (transmission tunnel) |
2G |
| W7 |
Ground (right wheelhousing in trunk) |
40L |
| X28/6 |
Driver head/thoraxbag connector |
26G |
| X28/7 |
Front passenger head/thoraxbag connector |
24G |
| X28/8 |
Driver seat ETR [GUS] connector (2-pin) |
28G |
| X28/9 |
Passenger seat ETR [GUS] connector (2-pin) |
30G |
| X55/4 |
Front passenger seat contacting strip |
37G |
| Z3/17 |
Circuit 15 (fused) connector sleeve |
39L |
| Z3/17 |
Circuit 15 (fused) connector sleeve |
31E |
| Z3/17 |
Circuit 15 (fused) connector sleeve |
29E |
| Z3/17 |
Circuit 15 (fused) connector sleeve |
4G |
| Z37/2 |
CAN engine bus (low) connector sleeve |
34G |
| Z37/3 |
CAN engine bus (high) connector sleeve |
35G |
