| L11 |
Transponder coil |
21L |
| M14/10 |
Fuel filler flap CL [ZV] motor |
2L |
| M14/5 |
Right door CL [ZV] motor |
12L |
| M14/5s1 |
Right door CL [ZV] microswitch |
|
| M14/6 |
Left door CL [ZV] motor |
5L |
| M14/6s1 |
Left door CL [ZV] microswitch |
|
| N10/10 |
SAM control unit |
20A |
| N10/10 |
SAM control unit |
26A |
| N10/10 |
SAM control unit |
12A |
| N10/10 |
SAM control unit |
5A |
| N10/10f31 |
Fuse 31 |
3A |
| S15 |
Remote trunk opening switch |
25L |
| S17/8 |
Trunk lid rotary tumbler microswitch |
27L |
| S6/1 |
Cockpit switch group |
19L |
| S6/1s11 |
Inside unlock CL [ZV] switch |
|
| S6/1s12 |
Inside lock CL [ZV] switch |
|
| S87/6 |
Right door rotary tumbler microswitch |
14L |
| S87/7 |
Left door rotary tumbler microswitch |
7L |
| S88/9 |
Rear-end door handle switch |
23L |
| U1012 |
Valid up to 30/08/2010 |
2E |
| U1013 |
Valid as of 31/08/2010 |
3E |
| U23 |
Valid for convertibles |
27F |
| U606 |
Valid for all except convertibles |
24F |
| W11/7 |
Ground (tank neck) |
30G |
| W43 |
Ground (outside left fire wall) |
11C |
| W43 |
Ground (outside left fire wall) |
9C |
| W6 |
Ground (left wheelhouse in luggage compartment) |
23G |
| W6 |
Ground (left wheelhouse in luggage compartment) |
27G |
| W6 |
Ground (left wheelhouse in luggage compartment) |
25G |
| W7 |
Ground (right wheelhouse in luggage compartment) |
30E |
| X35/1 |
Left door separation point |
9E |
| X35/1 |
Left door separation point |
5G |
| X35/2 |
Right door separation point |
11E |
| X35/2 |
Right door separation point |
12G |
| Z19/1 |
CL [ZV] "open" connector sleeve |
4F |
| Z19/2 |
CL [ZV] "closed" connector sleeve |
1E |
| Z19/2 |
CL [ZV] "closed" connector sleeve |
14E |
| Z19/2 |
CL [ZV] "closed" connector sleeve |
6E |
| Z21/6 |
CL [ZV] status "open" connector sleeve |
12E |
| Z21/6 |
CL [ZV] status "open" connector sleeve |
8E |
| Z6/35 |
Left door ground connector sleeve |
9H |
| Z6/36 |
Right door ground connector sleeve |
11H |
