| A1 |
Instrument cluster |
56L |
| A45 |
Fanfare horns and airbag clock spring contact |
29L |
| A53 |
Driver head/thoraxbag sensor |
23L |
| A54 |
Passenger head/thoraxbag sensor |
17L |
| B3 |
Driver seat adjustment detection sensor |
8L |
| B48/1 |
Driver-side frontal acceleration sensor |
19L |
| B48/2 |
Passenger-side frontal acceleration sensor |
14L |
| B48/3 |
Belt tension sensor |
62L |
| B48/3x1 |
Belt tension sensor connector |
|
| B48/4 |
Seat occupied recognition pressure sensor |
64L |
| B48/4x1 |
Seat occupied recognition pressure sensor connector |
|
| B48/7 |
Driver door pressure sensor |
44L |
| B48/8 |
Front passenger door pressure sensor |
49L |
| E16 |
Automatic child seat recognition airbag OFF indicator lamp |
6L |
| N10/10 |
SAM control unit |
3L |
| N10/10f18 |
Fuse 18 |
4L |
| N110 |
Weight Sensing System (WSS) control unit |
63A |
| N110 |
Weight Sensing System (WSS) control unit |
60A |
| N2/7 |
Restraint systems control unit |
5A |
| N2/7 |
Restraint systems control unit |
12A |
| N2/7 |
Restraint systems control unit |
20A |
| N2/7 |
Restraint systems control unit |
28A |
| N2/7 |
Restraint systems control unit |
36A |
| N2/7 |
Restraint systems control unit |
45A |
| N2/7 |
Restraint systems control unit |
53A |
| R12/16 |
Left windowbag squib |
9L |
| R12/17 |
Right windowbag squib |
10L |
| R12/20 |
Driver head/thoraxbag squib |
37L |
| R12/21 |
Front passenger head/thoraxbag squib |
35L |
| R12/24 |
Front passenger kneebag squib |
52L |
| R12/25 |
Driver kneebag squib |
51L |
| R12/27 |
Driver belt force limiter |
11L |
| R12/32 |
Driver reel tensioner squib |
32L |
| R12/33 |
Front passenger reel tensioner squib |
33L |
| R12/37 |
Driver-side anchor fitting tensioner squib |
13L |
| R12/37x1 |
Driver anchor fitting tensioner connector |
|
| R12/4 |
Front passenger airbag squib 1 |
25L |
| R12/5 |
Front passenger airbag squib 2 |
26L |
| S68/3 |
Driver seat belt buckle restraint systems switch |
39L |
| S68/4 |
Front passenger seat belt buckle restraint systems switch |
42L |
| U592 |
Valid for windowbag |
8A |
| W26 |
Ground (transmission tunnel) |
2G |
| W6 |
Ground (left wheelhouse in luggage compartment) |
20K |
| W7 |
Ground (right wheelhouse in luggage compartment) |
61K |
| W7 |
Ground (right wheelhouse in luggage compartment) |
15K |
| W83 |
Ground (transmission tunnel) |
46K |
| X28/10 |
Driver seat adjustment detection sensor connector |
7G |
| X28/6 |
Driver head/thoraxbag connector |
37G |
| X28/7 |
Front passenger head/thoraxbag connector |
35G |
| X28/8 |
Driver seat ETR [GUS] connector (2-pin) |
39G |
| X28/9 |
Front passenger seat ETR [GUS] connector (2-pin) |
41G |
| X35/1 |
Left door separation point |
44G |
| X35/2 |
Right door separation point |
48G |
| X55/4 |
Front passenger seat connector block |
58G |
| X99/17 |
Kneebag separation point |
51G |
| Z169 |
Shielding connector sleeve |
46C |
| Z20/52 |
Wire end tracer wire connector sleeve |
16J |
| Z20/52 |
Wire end tracer wire connector sleeve |
21J |
| Z20/53 |
Left tracer wire connector sleeve |
21H |
| Z20/53 |
Left tracer wire connector sleeve |
45E |
| Z20/54 |
Right tracer wire connector sleeve |
16H |
| Z20/54 |
Right tracer wire connector sleeve |
48E |
| Z3/17 |
Circuit 15 (fused) connector sleeve |
60K |
| Z3/17 |
Circuit 15 (fused) connector sleeve |
42E |
| Z3/17 |
Circuit 15 (fused) connector sleeve |
39E |
| Z3/17 |
Circuit 15 (fused) connector sleeve |
4G |
| Z37/2 |
CAN engine bus (low) connector sleeve |
55G |
| Z37/3 |
CAN engine bus (high) connector sleeve |
56G |
