| A1 |
Instrument cluster |
25A |
| A1 |
Instrument cluster |
5A |
| A1 |
Instrument cluster |
43A |
| A1 |
Instrument cluster |
12A |
| A1 |
Instrument cluster |
36A |
| A1e1 |
Left tern signal indicator lamp |
29A |
| A1e15 |
Airbag indicator and warning lamp |
21A |
| A1e17 |
ABS indicator lamp |
15A |
| A1e18 |
Electric steering indicator lamp |
45A |
| A1e2 |
Right turn signal indicator lamp |
30A |
| A1e26 |
"CHECK ENGINE" MIL |
31A |
| A1e3 |
High beam indicator lamp |
12A |
| A1e30 |
Oil pressure warning lamp |
20A |
| A1e41 |
ESP warning lamp |
22A |
| A1e5 |
Alternator charge monitoring and warning lamp |
24A |
| A1e54 |
Coolant temperature warning lamp |
32A |
| A1e66 |
Tire pressure monitor warning lamp |
26A |
| A1e67 |
Low beam indicator lamp |
10A |
| A1e7 |
Brake fluid and parking brake warning lamp |
14A |
| A1e8 |
Instrument illumination |
3A |
| A1e9 |
Seat belt warning lamp |
23A |
| A1p13 |
Multifunction display |
18A |
| A1p8 |
Electronic speedometer |
19A |
| A2/1 |
smart radio 9 |
21L |
| A2/2 |
smart radio 10 |
22L |
| A2/3 |
smart Entry radio |
25L |
| A2/4 |
smart Premium radio |
26L |
| A45 |
Fanfare horns and airbag clock spring contact |
32L |
| A45 |
Fanfare horns and airbag clock spring contact |
44L |
| B14 |
Outside temperature display temperature sensor |
18L |
| N10/10 |
SAM control unit |
9L |
| N10/10f12 |
Fuse 12 |
7L |
| N10/10f18 |
Fuse 18 |
6L |
| N23 |
Heater/AC operating unit |
36L |
| S111/2 |
Right steering wheel pitman arm |
3L |
| S6/1 |
Cockpit switch group |
30L |
| U1010 |
Valid for radio with Premium sound system |
25K |
| U1011 |
Valid for radio without Premium sound system |
25L |
| U1012 |
Valid up to 30/08/2010 |
4E |
| U1012 |
Valid up to 30/08/2010 |
20G |
| U1012 |
Valid up to 30/08/2010 |
38K |
| U1013 |
Valid as of 31/08/2010 |
2E |
| U1013 |
Valid as of 31/08/2010 |
24G |
| U1013 |
Valid as of 31/08/2010 |
31G |
| U1013 |
Valid as of 31/08/2010 |
38K |
| U492 |
Valid for power steering |
10E |
| U493 |
Not valid for power steering |
12E |
| U494 |
Valid for SAL |
42E |
| U865 |
Valid for Entry radio |
25K |
| W9 |
Ground (left front, at lamp unit) |
9G |
| Z3/17 |
Circuit 15 (fused) connector sleeve |
5G |
| Z37/4 |
Power steering CAN bus connector sleeve (low) |
11G |
| Z37/5 |
Power steering CAN bus connector sleeve (high) |
11G |
| Z45 |
ATA [EDW] sensor supply circuit 30 connector sleeve |
7G |
| Z81 |
Circuit 58d connector sleeve |
29E |
