Components [07/2013 - 12/2013]: Illustration

Fig 1: Identifying Front Passenger Seat Belt Warning Light Replacement Components (1 Of 2)

GTY387870

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
