Combination Meter

Fig 1: Combination Meter Electrical Wiring Diagram (1 Of 2)
G07618146Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Combination Meter Electrical Wiring Diagram (2 Of 2)
G07618147Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
