DTC P0300, P0301, P0302, P0303, P0304: Random/Multiple Cylinder Misfire Detected, Cylinder 1 Misfire Detected, Cylinder 2 Misfire Detected, Cylinder 3 Misfire Detected, Cylinder 4 Misfire Detected: Wiring Diagram

Refer to DTC P0351  for the wiring diagram of the ignition system.

Fig 1: Ignition System Wiring Diagram

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
