2MT70 - Automatic Transaxle

Park - Engine Running





Neutral - Engine Running





EVT Mode Reverse





Reverse - Engine Running





EVT Mode Low - Engine Running





EVT Mode Low - Engine Off





Drive Range, First Gear





Drive Range, Second Gear





Drive Range, Third Gear





Drive Range, Fourth Gear





EVT Mode High - From Drive Range 4th Gear





Power Off Low Default





Power Off High Default
