Hood Sensor/Switch (For Alarm): Locations

Immobilizer Component Views

Front of Engine Compartment

1 - Forward Lamp Harness
2 - Hood Ajar Switch Connector
3 - Hood Ajar Switch
4 - Cooling Fan
