Special Tools

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS CORP.	J 3289-20 Holding Fixture Base Assembly
Courtesy of GENERAL MOTORS CORP.	J 4670-01 Clutch Spring Compressor
Courtesy of GENERAL MOTORS CORP.	J 6125-1B Slide Hammer with Adapter
Courtesy of GENERAL MOTORS CORP.	J 6125-B Slide Hammers
Courtesy of GENERAL MOTORS CORP.	J 8001 Dial Indicator Set
Courtesy of GENERAL MOTORS CORP.	J 8059 Snap Ring Pliers - Parallel Jaw
Courtesy of GENERAL MOTORS CORP.	J 8092 Driver Handle
Courtesy of GENERAL MOTORS CORP.	J 21867 Pressure Gage
Courtesy of GENERAL MOTORS CORP.	J 22888-D Side Bearing Remover Kit
Courtesy of GENERAL MOTORS CORP.	J 23129 Universal Seal Remover
Courtesy of GENERAL MOTORS CORP.	J 23327 Clutch Spring Compressor
Courtesy of GENERAL MOTORS CORP.	J 23907 Slide Hammer with Bearing Adapter
Courtesy of GENERAL MOTORS CORP.	J 25018-A Clutch Spring Compressor Adapter
Courtesy of GENERAL MOTORS CORP.	J 25025-8 Dial Indicator Mounting Post
Courtesy of GENERAL MOTORS CORP.	J 26900-13 Magnetic Indicator Base
Courtesy of GENERAL MOTORS CORP.	J 26941 Bushing and Bearing Remover- 3-4 in
Courtesy of GENERAL MOTORS CORP.	J 26958 Output Shaft Aligner and Load Tool
Courtesy of GENERAL MOTORS CORP.	J 26958-10A Adapter Plug
Courtesy of GENERAL MOTORS CORP.	J 26958-10B Adapter Plug
Courtesy of GENERAL MOTORS CORP.	J 28540-A Torque Rod Adjuster
Courtesy of GENERAL MOTORS CORP.	J 28585 Snap Ring Remover
Courtesy of GENERAL MOTORS CORP.	J 28664-B Transmission Holding Fixture
Courtesy of GENERAL MOTORS CORP.	J 28677 Bearing Installer - Drive Sprocket Support
Courtesy of GENERAL MOTORS CORP.	J 29130 Axle Shaft Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 29569-1 Turbine Shaft Seal Installer (Expander)
Courtesy of GENERAL MOTORS CORP.	J 29569-2 Turbine Shaft Seal Installer (Compressor)
Courtesy of GENERAL MOTORS CORP.	J 29829-1A Turbine Shaft Seal Installer (Converter Side) Expander
Courtesy of GENERAL MOTORS CORP.	J 29829-2 Turbine Shaft Seal Installer (Converter Side) Compressor
Courtesy of GENERAL MOTORS CORP.	J 33381-A Clutch Assembly Remover/Installer
Courtesy of GENERAL MOTORS CORP.	J 33386-A Input Shaft End Play Tool for 4T60-E/4T65-E
Courtesy of GENERAL MOTORS CORP.	J 34094-A Thermo Element Height Gage
Courtesy of GENERAL MOTORS CORP.	J 34115 Sprocket Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 34126 Sprocket Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J 34129 Sprocket Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J 34741-A Input Shaft Seal Installer Set
Courtesy of GENERAL MOTORS CORP.	J 34741-1 Input Shaft Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 34741-2 Input Shaft Seal Pusher
Courtesy of GENERAL MOTORS CORP.	J 34741-3 Input Shaft Seal Compressor
Courtesy of GENERAL MOTORS CORP.	J 35138 Converter End Play Checker
Courtesy of GENERAL MOTORS CORP.	J 35616 GM-Approved Terminal Test Kit
Courtesy of GENERAL MOTORS CORP.	J 35944-A Cooler Flusher Fluid
Courtesy of GENERAL MOTORS CORP.	J 35944-22 Transmission Oil Cooler Flushing Fluid
Courtesy of GENERAL MOTORS CORP.	J 36850 Transjel Lubricant
Courtesy of GENERAL MOTORS CORP.	J 37096 Flywheel Holder
Courtesy of GENERAL MOTORS CORP.	J 37292-B Axle Seal Protector
Courtesy of GENERAL MOTORS CORP.	J 37361 Input Clutch Inner Piston Seal Protector
Courtesy of GENERAL MOTORS CORP.	J 37362 Third Clutch Piston Seal Protector
Courtesy of GENERAL MOTORS CORP.	J 37623 10 1/2 inch Pinion Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J 38358-A Clutch Assembly Remover/Installer
Courtesy of GENERAL MOTORS CORP.	J 38385 Output Shaft Loading Tool Adapter
Courtesy of GENERAL MOTORS CORP.	J 38734 Intermediate Spring Compressor Adapter
Courtesy of GENERAL MOTORS CORP.	J 41103 Torque Converter Seal Remover
Courtesy of GENERAL MOTORS CORP.	J 41103-1 Torque Converter Seal Puller Legs 4T40-E
Courtesy of GENERAL MOTORS CORP.	J 41103-2 Torque Converter Seal Puller Bridge 4T40-E
Courtesy of GENERAL MOTORS CORP.	J 41103-3 Torque Converter Seal Support Body 4T40-E
Courtesy of GENERAL MOTORS CORP.	J 41991 Bearing Remover/Installer
Courtesy of GENERAL MOTORS CORP.	J 41992-1 2nd Clutch Piston Protector
Courtesy of GENERAL MOTORS CORP.	J 41992-2 2nd Clutch Piston Adapter
Courtesy of GENERAL MOTORS CORP.	J 41992-3 2nd Clutch Piston Installer
Courtesy of GENERAL MOTORS CORP.	J 42562 Axle Removal Wedge
Courtesy of GENERAL MOTORS CORP.	J 43425 Output Shaft Loading Tool Adapter 4T60-E/4T65-E
Courtesy of GENERAL MOTORS CORP.	J 43442 Flywheel Holder
Courtesy of GENERAL MOTORS CORP.	J 44152 Jumper Harness (20 pins)
Courtesy of GENERAL MOTORS CORP.	J 44246 Solenoid Testing Kit
Courtesy of GENERAL MOTORS CORP.	J 44465 Holding Fixture Adapter
Courtesy of GENERAL MOTORS CORP.	J 44467 Output Shaft Assembly Remover/Installer
Courtesy of GENERAL MOTORS CORP.	J 44472 End Play Checking Tool
Courtesy of GENERAL MOTORS CORP.	J 44538 Torx® 30+
Courtesy of GENERAL MOTORS CORP.	J 44755 Holding Fixture
Courtesy of GENERAL MOTORS CORP.	J 45096 Transmission Oil Cooling System Flush and Flow Test Tool
Courtesy of GENERAL MOTORS CORP.	SA 9165T Oil Cooler Line Flusher
