Engine Controls Components View - Front
WARNING: This page is about a different variant/trim than selected.
Courtesy of GENERAL MOTORS CORP.
| Callout |
Component Name |
| 1 |
Ignition Coil Housing |
| 2 |
Ignition Control Module (ICM) |
| 3 |
Fuel Rail and Injectors |
| 4 |
Evaporative Emissions (EVAP) Canister Purge Solenoid |
| 5 |
Throttle Body and Throttle Actuator Control (TAC) Module |
