Converter Charge Valve

The converter charge valve limits TCC apply pressure to prevent torque converter damage from over-pressure. During cold operation the converter limiting valve can not exhaust enough oil to keep converter pressure in a normal operating range. When apply (converter feed) pressure goes above normal operating pressure the valve will unseat and dump excess oil pressure to the transaxle sump.
