Upper

REMOVAL
1. Drain cooling system below engine outlet neck.
2. Remove clamp and hose from radiator inlet neck.
3. Remove clamp and hose from engine inlet neck.
4. Remove hose from vehicle.

INSTALLATION
1. Install hose and clamp on engine outlet neck. Position clamp at 1 o'clock.
2. Install hose and clamp on radiator inlet neck. Position clamp at 1 o'clock.
3. Fill cooling system and leak test.
