Diagnostic Aids
An intermittent condition is likely to be caused by a poor connection at the passenger inflator module harness connector terminals A and B, SDM terminals A5 and A6, or a poor wire to terminal connection to circuits 1403 or 1404. The test for this DTC is only run while the AIR BAG warning light is performing the bulb check, unless DTC 17 or 26 is detected. When a PDT "Clear Codes" command is issued and the malfunction is still present, the DTC will not reappear until the next ignition cycle.
