Radio Front Speaker Grille Replacement

Fig 1: Identifying Radio Rear Speaker Grille
G09435317Courtesy of SAAB-SCANIA OF AMERICA, INC.
Callout Component Name
1 Radio Front Speaker Grille Assembly
Procedure
  1. Use a flat-bladed plastic trim tool to aid in the removal of the speaker grille.
  2. Disconnect the electrical connector.
  3. When replacing the speaker grille, transfer all necessary components.
