DVD unit (729): Connection
The DVD unit is supplied with +30 on pin 2 and grounded on pin 1. The O-bus has its own connection where pin 1 receives the signal and 2 transmits the signal.
DVD UNIT CONNECTION
| Pin no. |
Signal type |
Description |
| 1 |
Ground |
|
| 2 |
+30 |
|
| 1 |
O-bus |
Reception. Own connection. |
| 2 |
O-bus |
Transmission. Own connection. |
